The AOD (automatic overdrive) is a four-speed automatic transmission with overdrive. Introduced in 1980, it was Ford's first four-speed automatic overdrive transmission. The gearset design is based on the Ford 'X' automatic transmissions used during the 1950s, 60s, and 70s. The AOD replaced many of Ford's older transmissions such as the C4, C5, and light duty applications of the FMX.

Ford Transmission Repair Manuals,ATSG Transmission Manuals. The 6R60/75/80 is a ZF6HP style transmission specifically fitted for Ford. This transmission can be found in the 2005 Navigator, 2006 Explorer and Mountaineer, 2007 Expedition, 2008 F150 and 2010 Mustang. AODE Transmission Repair Manual, 4R70W Transmission Repair Manual, E40D.

Nov 06, 2019  Ford AOD-E Transmission Service and Repair Manual PDF free online. This manual provides the procedures necessary to service, repair or overhaul this unit, along with the electrical diagnosing methods necessary. You will notice that several pieces of diagnosing equipment that will be necessaiy for quick and accurate diagnosing. Sep 10, 2018  ATSG FORD AOD-E 4R70W Transmission Technical Manual is necessary to diagnose, overhaul and/or repair the AODE / 4R70W transmission. Ford AODE / 4R70W Transmission found in 1993 and up Crown Victoria and Town Car. Covers transmission assembly, dis-assembly, diagnosis, troubleshooting, electronic controls & operation. Shelburneartcenter.org has a large collection of images like 4r70w Transmission Diagram, Ford 4r70w Automatic Transmission Repair Manual Pdf Online Download dan ford 4r70w automatic transmission repair manual. This image is of type JPG. In addition, this. Frictions, disks and clutch are made of special alloy of ultra-high-strength. If you wondered how to repair 4R70W automatic gearbox, be sure – it’s pretty easy. (AODE) transmission What do you need for repair? Download scheme for 4R70 (AOD-E) Download manual for 4R70 (AOD-E) Download repair manual for 4R70 (AOD-E) Most Popular.

• 3AODE

History[edit]

In 1962 Ford began working on a new type of automatic transmission that would emphasize fuel economy and driveability. The new transmission was built around the Ravigneaux planetary gearset of the 'X' transmissions. Where many transmissions had a fourth gear added on as an afterthought, Ford's new transmission was designed with a fourth gear integrated into the gearset. Because it was based on the 'X' transmissions, its gear ratios from 1-3 were the same with the fourth being 0.67:1. The transmission featured a split-torque application for third gear as well as a lockup in the torque converter. The XT-LOD was initially abandoned in 1966 but design began again in 1974 as a result of rising gas prices. The project was shelved with a design that lacked a dampener in the torque converter but after the project was revisited a dampener ultimately made its way into the final design. The transmission was introduced when Ford started to downsize its full size line in 1979. Initially called XT-LOD (Extension Lock-Up Overdrive) its name was changed when revisited in 1974 to FIOD (Ford Integrated Overdrive) and then to its final name in 1979, the Ford AOD transmission.[3]

Applications:

• 1980–1986 Ford LTD
• 1980–1993 Ford Thunderbird
• 1980–1993 Mercury Cougar
• 1984–1993 Ford Mustang
• 1980–1986 Mercury Marquis
• 1983–1993 Ford Econoline
• 1983–1991 Ford LTD Crown Victoria
• 1983–1992 Mercury Grand Marquis
• 1982–1993 Ford Bronco
• 1981–1992 Lincoln Town Car
• 1980–1987 Lincoln Continental
• 1980–1983 Continental Mark VI
• 1984–1985 Continental Mark VII
• 1986–1992 Lincoln Mark VII
• 1992 Ford Crown Victoria
• 1980–1993 Ford F-Series

Gear ratios[edit]

• First: 2.400:1
• Second: 1.467:1
• Third: 1.00:1
• Overdrive: 0.667:1
• Reverse: 2.00:1

AODE[edit]

The AOD was redesigned with electronic controls in 1992, becoming the AOD-E. It was mainly intended for the new ModularV8 at first, but it was also adapted to the old AOD bell-housing for vehicles still powered by pushrod-valve engines. While the AOD and AOD-E are similar to each other (oil pans, casings, bell-housing, and internals), they are not interchangeable with each other because the AOD-E's shift points are controlled electronically from a combination of solenoids and the Powertrain Control Module (PCM) while the AOD's shift points are hydraulically controlled by a throttle valve rod.

Applications:

• 1992–1994 Lincoln Town Car
• 1992 and up Ford F-Series trucks and E-Series vans
• 1993–1994 Ford Crown Victoria
• 1993–1994 Mercury Grand Marquis
• 1994–1995 Ford Mustang

4R70W[edit]

A revised version of the AOD-E Transmission was released in 1993 with the Lincoln Mark VIII. Unlike the AOD-E, both 1st and 2nd gear ratios in the 4R70-W are numerically higher. Giving the Transmission a better mechanical advantage and in turn, better take-off acceleration, slightly lower fuel consumption, and designed for better gearset strength. On vehicles powered by the 5.4L V8, a stronger gearset is used than in normal duty 4R70Ws. In 1998, due to durability concerns, the intermediate one-way roller clutch was replaced with a mechanical diode providing extra holding capacity and longer service.

While there is some speculation that the 70 can be multiplied by 10 to indicate the ft-lb of torque this transmission is capable of handling including torque converter multiplication, (i.e. 700 ft-lb of torque), there is no reliable source indicating this. In fact a Ford document stated that the 2003 'Expedition's 4R70W transmission is rated to handle up to 506 foot-pounds of torque, which provides a large performance cushion beyond the peak torque rating of Expedition's largest available engine.' https://web.archive.org/web/20040908180047/http://media.ford.com/products/presskit_display.cfm?vehicle_id=548&press_subsection_id=423&make_id=92 . It is more plausible that the number indicates the torque handling capability in N-m, as 506 lb-ft converts to 686 N-m which could be rounded to 700 N-m. The '70' may also refer to the transmission's torque capacity after torque converter multiplication which occurs at low rpm's when the torque converter is more 'elastic'. 4R70W indicates 4 gears, Rear wheel drive and Wider gear ratio compared to the AODE.

The gear ratios are:

• First: 2.84 :1
• Second: 1.55 :1
• Third: 1.00 :1
• Overdrive: 0.70 :1
• Reverse: 2.32 :1

Applications:

• • 1993–1998 Lincoln Mark VIII
  • 1993–2003 Ford F-Series
  • 1994–1997 Ford Thunderbird
  • 1995–2004 Ford Crown Victoria
  • 1996–2001 Ford Explorer
  • 1993–2004 Lincoln Town Car
  • 1994–1997 Mercury Cougar
  • 1995–2004 Mercury Grand Marquis
  • 2003 Mercury Marauder
  • 1997–2004 Ford Expedition
  • 1997–2001 Mercury Mountaineer
  • 1996–2004 Ford Mustang
  • 2004–2005 Rover 75 V8

4R75W[edit]

In 2003 Ford revised the 4R70W transmission with a stronger ring gear that had 24 lugs, as opposed to 6, for the output shaft sensor (OSS) to read off of, a new torque converter, a revised front pump assembly, and a vehicle speed sensor (VSS) that compliments the OSS to improve shift quality and efficiency. These improvements allowed the 4R75W to handle more power while being more efficient and economical. While not used on all 2003 model year vehicles, the 4R75W/E transmissions eventually replaced the 4R70W/E.

Newer transmissions that are referred to as 4R70E or 4R75E have modifications that compliment Fords switching to throttle by wire. The PCM was given a more powerful microprocessor and Ford added a turbine speed sensor to the transmission. This allows the PCM to know the speed of the input shaft after the torque converter which is used in combination with crankshaft speed to detect the amount of slipping going on in the torque converter. This information provides PCM with the basis for fully electronic shift scheduling which limits 'hunting' and fine-tunes shift speed and feel. It lets the PCM know what the torque will be in the next gear so it can choose the shift points based on the vehicle's projected performance in the next gear. Coupled with the electronic throttle strategy, the transmission computes the output torque required to maintain the vehicle speed, and chooses the correct gear and converter state accordingly.

Modification[edit]

The most practical modification for the 4R70W is the J-mod. It involves modifying the valve body separator plate and gaskets as well as changing or removing accumulator springs to alter the shift timing of the transmission. While these modifications can be done to 4R75W transmission, the results are not as dramatic as some of the details of the J-Mod (bigger holes in the separator plate and gasket) were done to the transmission in its design. These modifications are specified by one of the Ford engineers who designed the transmission. It offers faster engagement, quicker shifting, smoother operation, and increased service life. All parts can be bought at Ford dealers for less than $60 including the fluid.

A 20,000+ GVW cooler is highly recommended for all vehicles. Breakdown of the transmission fluid often results in 'converter shudder' (feels like driving over rumble strips) where converter tries to maintain a steady slip rate during lock-up, but alternates between slipping and grabbing. Frequent fluid changes, especially when used for towing, are the single best method to prevent shudder. Shudder occurs because the torque converter never fully enters 'lock-up', and ends up bouncing in and out of lock-up to slip. This causes the engine to flare up and then down again as the clutch cannot hold back the power of the engine.

4R7xx Usage[edit]

2002

4R70W used in all applications:

2003

Ford Automatic Transmission Rebuild Manuals

• Ford Mustang (GT and Mach 1)

• 5.4 L Ford F-Series, Ford E-Series, and Ford Expedition
• 4.6 L Ford E-Series Van, 4.2 L and 4.6 L F150

• 3.8L V6 Ford Mustang
• Ford Panther platform Cars: Ford Crown Victoria, Mercury Grand Marquis, Mercury Marauder and Lincoln Town Car

2004

• 5.4 L-3v Triton F150

• 4.6 L Triton F150(except F150 Heritage)

• Ford Mustang (GT and Mach 1)
• 5.4 L V8 2V trucks Ford E-Series Van, and Ford Expedition

• 3.9 L V6 Ford Mustang
• 4.6 L V8 Ford E-Series
• 4.6 L V8 Ford Expedition
• Ford Panther platform Cars: Ford Crown Victoria, Mercury Grand Marquis, and Lincoln Town Car
• 4.2 L and 4.6 L Ford F150 Heritage

2005

4R75E used in 5.4 L V8 2-valve and 3-valve trucks:

• F150 Heritage (sold only in Mexico)

• 4.6 L Ford E-Series
• 4.6 L Ford Panther platform Cars: Ford Crown Victoria, Mercury Grand Marquis, and Lincoln Town Car
• 4.6 L Ford F150 except F150 Classic (sold only in Mexico)

2006 to 2008

• Ford F150 Heritage (sold only in Mexico)

• 2006-2011 Ford Panther platform Cars: Ford Crown Victoria, Mercury Grand Marquis, and Lincoln Town Car.
• 2007-2008 4.2 L, 4.6 L, 2004-2008 5.4 L Ford F-Series except F150 Heritage (sold only in Mexico)
• 2006 Ford Expedition
• 2006-2013 4.6 L, 5.4 L Ford E-Series
